Cummins QSK23 engine with Zoomlion customized hydraulic system, realize P and E Stable operation. The fuel consumption is 6% lower than that of previous generation, and increase the work efficiency by 8%.
Original imported hydraulic component, advanced hydraulic technology, can provide a variety of modes of confluence regeneration to improve work efficiency; the boom mode selection to reduce the buffer, prolong the service life of the machine..
Equipped with an 8-inch large screen display and a new human-computer interaction operating system, you can view machine parameters and fault alarms at any time. The vehicle is equipped with 10 high-brightness LEDs, 2 inspection-lights of pump room engine compartment, 2 lights of stairs, facilitating night work and maintenance..
| Parameter | Unit | Value |
| Operating Weight | kg | 74000 |
| Bucket Capacity | m³ | 3.6-5.4 |
| Model | / | X15 |
| Engine Power | kW/rpm | 373/1800 |
| Displacement | L | 15 |
| Maximum torque | N·m/rpm | 2169/1400 |
| Emission Standards | / | Tier 4f、EU Stage V |
| Swing Speed | r/min | 7 |
| Travel Speeds（Max/Min） | km/h | 4.2/3.0 |
| Maximum Traction | kN | 536 |
| Bucket Digging Force | kN | 397 |
| Arm Digging Force | kN | 328 |
